Power supply : AC220V±10% 50HZ（60HZ).
Rated power : 0.4KW.
Single pass weight range : ≤20Kg.
Machine direction : Left to Right or Right to Left.
Accuracy range ≥FE：0.6mm ≥CU：1.0mm ≥SUS：1.2mm
Highest precision : ≥0.5mm
Conveyor speed : 25-30m/min / adjustable.
The highest speed (needs customization) : 60 pcs/min.
Conveyor belt size : 1400mm(L) * 350mm(W).
Conveyor belt height from the floor : 700mm.
Conveyor belt material : Food grade white belt.
Detection tunnel width : 400mm.
Detection tunnel height : 150mm.
Alarm methods : Alarm, LED light, auto-stop.
Rejection method (needs customization) : Pusher ,flap ,air ,etc.
Control system High-speed A/D sampling controller.
Product parameter record : 12.
Machine dimension : 1400mm(L) * 850mm(W) * 950mm(H).
Working environment Temperature: -30℃～50℃, Humidity: 30%～75%
Machine material 304 stainless steel
